China Made Vertical LSR Injection Moulding Machine
Contact Person : Angelina
Phone Number : 15918448424
WhatsApp : +8615918448424
| Minimum Order Quantity : | >1 | Price : | Negotiation |
|---|---|---|---|
| Packaging Details : | wooden case | Delivery Time : | 45 workdays |
| Payment Terms : | L/C, T/T | Supply Ability : | 50 sets per month |
| Place of Origin: | China | Brand Name: | TYM |
|---|---|---|---|
| Certification: | CE/ISO | Model Number: | TYM-5058 |
|
Detail Information |
|||
| Type: | Vertical | Condition: | New |
|---|---|---|---|
| Certification: | CE/ISO | Product Name: | Vertical Injection Moulding Machine For Injection Machine For Medical Device |
| Warranty: | 1 Year | Openning Stroke: | 200-700mm |
| High Light: | low pressure overmolding machine,cable overmolding machine |
||
Product Description
Vertical Injection Moulding Machine For Injection Machine For Medical Device
For double sliding board LSR machine, one upper moldboard and two lower moldboards are installed, which improves the production efficiency. The sliding out structure on the machine makes the production more conveniently and more safely.
Machine Model Parameter
| Machine Model | Shot Volume | Injection Rate | Injection Pressure | Clamping Force | Opening Stroke | Tie-Bars Force | Ejection Force | Ejection Stroke | Pump Pressure | Machine Weight | Motor Power | Machine Dimension |
| TYM-W4545 | 148g | 30g/s | 700kg/cm2 | 130T | 200-700mm | 450*450mm | 4.3T | 150mm | 21Mpa | 5.2T | 12.1KW | 4.0*1.2*1.9m |
| TYM-W5050 | 270g | 30g/s | 700kg/cm2 | 150T | 200-700mm | 500*500mm | 4.3T | 150mm | 21Mpa | 5.3T | 12.1KW | 4.2*1.4*1.9m |
| TYM-W5555 | 270g | 30g/s | 700kg/cm2 | 160T | 200-700mm | 550*550mm | 4.3T | 150mm | 21Mpa | 5.6T | 12.1KW | 4.5*1.6*2.0m |
TYM SERVICE
| Pre -sale service | * Provide investment budget and plant planning; * Provide a whole set of solutions about machine and mold according to products that customers offered. |
| On-sales service | * Provide installation and new machine debugging services for users who purchase Tianyuan machine. *Free tranning for your staff who can operate and maintain the machine independently in your factory. |
| After-sales service | * Timely dispatch personnel to the user's site to solve after-sales problems and solve difficult technical problems; * After product upgrading, the upgrading work of previous users shall be given priority as required; |
