Integrated Double Colour Liquid Silicone Injection Moulding Machine 700kg / C㎡ Injection Pressure

Minimum Order Quantity : 1 set Price : Negotiation
Packaging Details : Plywood box Delivery Time : 60 work days
Supply Ability : 10 sets / month
Place of Origin: CHINA Brand Name: TYM
Certification: CE, ISO Model Number: TYM-L3140

Detail Information

Double Colour Injection Moulding Machine: Integrated Double Colour Liquid Silicone Injection Moulding Machine 700kg / C㎡ Injection Pressure Clamping Force: 240T
Shot Volume: 165*2 G Opening Stroke: 200-500MM
Injection Rate: 30g/s Injection Pressure: 700kg/c㎡
Ejection Force: 4.3T Motor Power: 12.1KW
High Light:

two color injection molding machine

,

double shot injection molding

Product Description

Integrated Double Colour Liquid Silicone Injection Moulding Machine 700kg / C㎡ Injection Pressure



1. Realize the production demand of double station and two color

With two mold closing spaces and two feeding systems, liquid silica gel with different colors and hardness can be formed in the machine at the same time.

2. Dual servo system

New tym series control computer, parametric settings, to achieve the reliability of mechanical operation, stability, accuracy and so on

3. 50% less than that of peers, and 100000 yuan / set can be saved every year

4. The color paste mixing can realize numerical control, and the accuracy can be as high as 0.1%

5. 100000 hours of trouble free operation



LSR double color injection molding machine of model TYM-L3140:



Integrated Double Colour Liquid Silicone Injection Moulding Machine 700kg / C㎡ Injection Pressure 0















The vertical double color 240T direct pressure LSR injection molding machine



Injection Unit
Shot Volume 165*2 g (can be adjusted)
Injection Rate 30 g/s
Injection Pressure 700kg/cm³
Clamping Unit
Clamping Force 240T
Opening Stroke 200-500 mm
Tie-Bars Pace 500*500mm * Φ 1400mm
Ejection Force 4.3 T
Ejection Stroke 150 mm
Others
Motor Power 12.1 KW
Pump Pressure 21 Mpa
Machine Weight 9.7 T
Machine Dimension 3.2*2.1*4.0 M





OUR SERVICES



Pre-sale service
According to the customer’s investment budget, plant planning and other forms of pre-sales services to ensure customer's planning is reasonable, standardized and cost-saving, will provide matched mold and select suitable machine according to customer’s requirement.



On-purchase service
Enable to be familiar with the operation and maintenance of the TYM's machine.
1) Installation of LSR machine and new machine debugging service.
2) Machine operator training.
3) Training of technicians.


After-sales service
1) Free training for the operation and maintenance independently.
2) Help to solve and reply technical problem and question timely, TYM will arrange professional engineer for the instruction and will provide the technical guidance for free.
3) TYM will give priority to customer when the system on the LSR machine need to be upgraded.
