Horizontal Liquid Injection Molding Machine 2.4 * 1.6 * 3.4m Dimension

Minimum Order Quantity : »1 Price : Negotiation
Packaging Details : wooden case Delivery Time : 45 workdays
Payment Terms : L/C, T/T Supply Ability : 100 set year
Place of Origin: China Brand Name: TYM
Certification: CE/ISO9001 Model Number: TYM4545

Detail Information

Condition: New After-sales Service Provided: Engineers Available To Service Machinery Overseas,Online Support
Certification: CE,ISO9001 Power(kw): 12.1
Automatic: Yes Opening Stroke: 200-700mm
Injection Rate: 30g/s Style: Horizontal
Clamping Force: 130T Machine Dimension(l*w*h): 2.4*1.6*3.4m
Product Name: Liquid Injection Molding Machine Horizontal Injection Molding Machine Warranty: 1 Year
Ejector Stroke: 150mm
High Light:

electric injection moulding machine

,

liquid silicone rubber injection molding machine

Product Description

Liquid Injection Molding Machine Horizontal Injection Molding Machine



TYM LSR Machines are Specialization and integration, more efficient, more energy-efficient, save more cost of production.
TYM LSR injection machine include the Horizontal machine, Vertical machine, double-color machine, it is the whole-in-one LSR machine, the function is powerful, very easy to operate, low energy consumption, and it also can save much material when cleaning and changing material, Expect the local market, our LSR machine also sells very well in many other foreign countries, it is suitable for producing medical products, baby products, electronic products, sex toy, overmold and inserts LSR parts. the conveyer on host machine adopts specialized numerical control system.​



Horizontal Liquid Injection Molding Machine 2.4 * 1.6 * 3.4m Dimension 0



Machine Model Parameter



Machine Model Shot Volume Injection Rate Injection Pressure Clamping Force

Opening Stroke

Tie-Bars Force Ejection Force Ejection Stroke Pump Pressure Machine Weight Motor Power Machine Dimension
TYM-W4545 148g 30g/s 700kg/cm2 130T 200-700mm 450*450mm 4.3T 150mm 21Mpa 5.2T 12.1KW 4.0*1.2*1.9m
TYM-W5050 270g 30g/s 700kg/cm2 150T 200-700mm 500*500mm 4.3T 150mm 21Mpa 5.3T 12.1KW 4.2*1.4*1.9m
TYM-W5555 270g 30g/s 700kg/cm2 160T 200-700mm 550*550mm 4.3T 150mm 21Mpa 5.6T 12.1KW 4.5*1.6*2.0m



Horizontal Liquid Injection Molding Machine 2.4 * 1.6 * 3.4m Dimension 1

Horizontal Liquid Injection Molding Machine 2.4 * 1.6 * 3.4m Dimension 2

Our Service & Advantages:
1. Reply your enquiry in 24 working hours.
2. Experienced staff answers all your questions in fluent English.
3. More than 10 years experience to LSR injection molding machine in China.
4. Tianyuan can design the LSR injection molding equipment according to the customer's requirements, provide a whole set of solutions for the LSR equipments.
5. Our LSR injection molding machine is widely used in medical industry, food industry, infant industry , diving industry, insulator industry and other LSR production field.
6. According to the high quality, precise and reliable of the LSR injection molding machine, we help the customer to produce the refined LSR products and price ratio is in high performance in the LSR industry.
7. Welcome OEM and ODM.
